Hikvision DS-K1T502DBWX-C Access Control Terminal

The Hikvision DS-K1T502DBWX-C is an advanced access control terminal that combines security and communication functionalities in a single device. Equipped with a 2MP camera, it supports various authentication methods such as RFID, PIN, and Bluetooth, ensuring flexible access management. The terminal features two-way audio communication via the SIP protocol, allowing for real-time interaction. Its rugged design, with IP65 and IK09 ratings, ensures durability in various environmental conditions. The device can be remotely managed through the Hik-Connect mobile app, providing convenient control and monitoring.

Key Features:

• 2MP high-definition camera with a 110° horizontal and 81° vertical field of view

• Multiple authentication methods: RFID, PIN, Bluetooth, and QR code

• Two-way audio communication via SIP protocol

• Supports external access controllers via Wiegand protocol

• Remote management through the Hik-Connect mobile app

• IP65 and IK09 rated for protection against dust, water, and vandalism

• Compatible with various SIP servers including Asterisk, 3CX, and FreePBX

• Supports up to 100,000 cards and 300,000 events

Specifications:

• Camera: 2MP, H.264 and H.265 video compression standards

• Audio: Built-in omnidirectional microphone and loudspeaker

• Network Protocols: IPv4, SIP 2.0, RTSP, ISAPI

• Connectivity: RJ-45 Ethernet, RS-485, Wiegand (W26/W34), Bluetooth

• Power Supply: DC 12V ~ 24V, ≤12W

• Operating Temperature: -40°C to +70°C

• Dimensions: 160 mm × 80 mm × 30 mm

• Weight: Approximately 1.2 kg

Installation Notes:

• Surface mount installation

• Suitable for both indoor and outdoor environments

• Compatible with Hikvision’s video intercom systems for integrated communication
