Hikvision iDS-7204HQHI-M1/XT 4-Channel AcuSense 1U Hybrid DVR

The Hikvision iDS-7204HQHI-M1/XT is a 4-channel 1U AcuSense DVR designed for hybrid CCTV systems. It supports up to 4 analog inputs plus IP cameras, allowing up to 6 channels in enhanced IP mode. This DVR features facial recognition, perimeter protection, and advanced motion detection (Motion Detection 2.0) powered by deep learning to minimize false alarms.

It supports multiple video signals (HDTVI, AHD, CVI, CVBS, IP) and uses H.265 Pro+ compression to save storage while maintaining quality. Recording is supported up to 3K/5MP Lite at 12 fps. The device has one SATA HDD bay supporting up to 10 TB, multiple video outputs (HDMI, VGA, BNC), and audio input/output with two-way audio capability. Built for performance and reliability, it’s an ideal choice for professional security systems.

Key Features:

• 4 analog video inputs, hybrid support for IP cameras (up to 6 channels in enhanced IP mode)

• 1-channel facial recognition or 2-channel perimeter protection with deep learning

• Motion Detection 2.0 (human/vehicle classification) on all analog channels

• Multi-signal compatibility: HDTVI, AHD, CVI, CVBS, IP

• Compression formats: H.265 Pro+, H.265, H.264+, H.264

• Encoding capability up to 3K/5MP Lite at 12 fps

• Storage: 1 SATA bay, supports up to 10 TB HDD

• Video outputs: HDMI & VGA up to 1920×1080 resolution

• Audio: inputs (analog & coax), RCA output, two-way audio support

• Power supply: 12 VDC, max. 18 W

• Operating temperature: −10 °C to +55 °C, humidity 10–90% non-condensing

• Dimensions: 319 × 236 × 48 mm

• Weight: approx. 1.16 kg
