Hikvision DS-7608NXI-K1 8-Channel 1U AcuSense 4K NVR

The Hikvision DS-7608NXI-K1 is a high-performance 8-channel Network Video Recorder (NVR) designed for seamless integration with IP cameras. It supports up to 8 PoE (Power over Ethernet) ports, simplifying installation by providing both power and data transmission over a single cable. The NVR utilizes H.265+ video compression technology, offering efficient storage management without compromising video quality.

Equipped with AcuSense technology, the DS-7608NXI-K1 delivers intelligent analytics such as facial recognition, perimeter protection, and motion detection 2.0. These features enhance security by accurately identifying and responding to potential threats, reducing false alarms and manual monitoring efforts.

Ideal for medium to large-scale surveillance systems, this NVR provides reliable performance, advanced features, and ease of use, making it a valuable addition to any security infrastructure.

Key Features:

• 8 PoE Ports: Simplifies installation by delivering power and data over a single cable.

• H.265+ Compression: Reduces bandwidth and storage requirements while maintaining high video quality.

• AcuSense Technology: Includes AI-driven features like facial recognition, perimeter protection, and motion detection 2.0.

• Decoding Capacity: Supports up to 1 channel at 12 MP, 2 channels at 8 MP, 4 channels at 4 MP, or 8 channels at 1080p resolution.

• Playback: Offers 8-channel synchronous playback for efficient review of recorded footage.

• Storage: Compatible with 1 SATA interface for hard drive connection (up to 16 TB).

• Network Access: Features 8 independent PoE network interfaces and 1 self-adaptive 10/100/1000 Mbps Ethernet interface.

• User Interface: Supports HDMI and VGA video outputs, with independent output capabilities.

Specifications:

• Model: DS-7608NXI-K1

• Channels: 8 IP camera inputs

• Video Formats: H.265+/H.265/H.264+/H.264

• Decoding Capacity: Up to 1-ch@12 MP, 2-ch@8 MP, 4-ch@4 MP, or 8-ch@1080p

• Incoming Bandwidth: Up to 80 Mbps

• Audio Output: 1-ch, RCA (Linear, 1 KΩ)

• Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)

• Video Output: HDMI/VGA independent output

• Storage Interface: 1 SATA interface (up to 16 TB)

• PoE Ports: 8 independent PoE network interfaces

• Ethernet Interface: 1 self-adaptive 10/100/1000 Mbps Ethernet interface

• Dimensions: 1U rackmountable chassis

• Operating Conditions: -10°C to +55°C, Humidity: 10% to 90% (non-condensing)

• Power Supply: 12 VDC ± 25%, PoE (802.3af)

• Weight: Approximately 2.5 kg
